DVR-100A Rearview Mirror Car Recorder Vehicle DVR

DVR-100A Rearview Mirror Car Recorder Vehicle DVR

Description
DVR-100A is a wide angle rearview mirror with visible area of 300mm. It has high quality image sensor and lens to record image.
Furthermore, it's equipped with DVR module, which can start loop recording when vehicle engine is turned on.
The DVR module has high quality image sensor and lens to record image with 640*480 video resolution at 25 fps.
Moreover, it has built-in Lithium battery to serve as backup power such that the module can keep on recording for a period of
time when vehicle power is shut down.

Wide angle rearview mirror
Operating voltage : 12V
Visible area : 300 mm
Installation : Clip on. No need to remove original rear view mirror
Storage temperature : -30°C~+80°C
Operating Temperature : -10°C~+50°C
Weight : 310g
Dimension : 315mm * 85mm * 21mm (Without clamp)

DVR
Image sensor : VGA1/4" CMOS
LCD monitor : AUO 2.4 inch(480*234)
Video format : MPEG 4 ASF
Video resolution : 640*480 at 25 fps
SDHC support : Up to 8GB
Battery : Built-in Lithium rechargeable battery
Recording mode : Synchronized video and audio

Packaging Details
Generic package includes the following items :
(1) Digital Video Recorder
(2) White box
(3) User manual
